GV3 M06 to M80 single phase motor protection circuit breaker

• GV3 M06 to M80 single phase MPCB motor protection circuit breaker are mainly used for the overload and short circuit protection of the motor in AC 50/60Hz,rated voltage up to 660V,rated current 0.1-80A prower circuit,as a full-voltage starter to start and cut off the motor,under the AC3 load or for the overload and short circuit protection of the circuit and power equipment in the power distribution network.

• Technical parameters

Model	Rated current	Rated output power (KW)	Rated current range (A)		Order No.
			thermal overload tripping	Instantaneous over-current tripping
GV3-M(ME)	2..5	0.75	1.6-2.5	30	GV3-M07
	4	1.1/1.5	2.5-4	48	GV3-M08
	6	2.2	4-6	72	GV3-M10
	10	3/4	6-10	120	GV3-M14
	16	5.5/7.5	10-16	190	GV3-M20
	20	7.5/10	16-20	240	GV3-M21
	25	11	20-25	300	GV3-M25
	40	18.5	25-40	480	GV3-M40
	63	28	40-63	720	GV3-M63
	80	32	56-80	960	GV3-M80

• Accessories

Names of accessoris		Code	ttype of contacts	Installation place
Instantaneous auxiliary contacts		A01	1NO+1NC	the right of the breaker(1PC)
		A02	2NO

• Outline fitting dimension
